Notice: The Anti-slip battery Pad has changed into black color normal pad.

Do NOT have transparent logo pad.

Specifications:
Brand: FlyFishRC

Model: Volador VX3 / Volador VX3.5

Optional Version: 3 Inch / 3.5 Inch

Wheelbase: 144mm (3 Inch Version); 160mm (3.5 Inch Version)

Arm Thickness: 3.5mm
Top plate thickness: 2mm
Middle plate thickness: 2.4mm
Bottom plate thickness: 2.4mm
Keystone thickness: 3.5mm
CNC Side plate thickness: 5mm
Propeller size: 3~3.5 inch
Material: T700 carbon plate
FPV cam spacing: 19mm/20mm
VX3 Weight: 68.3g(with TPU parts)
VX3.5 Weight: 70.5g(with TPU parts)
Colour: Black,Tropical Mix (Optional)
VX3 Total Dimensions:118x135mm
VX3.5 Total Dimensions:127.5x148mm
Stack mounting holes: 20mm*20mm/25.5mm*25.5mm(M2)
VTX mounting holes: 20mm*20mm/25.5mm*25.5mm(M2)

Features:

Superior Design: These frames offer a 5-inch flying experience, crafted with a Squashed X configuration for maximum control and system compatibility.

Quality Material: The frames are built with high-strength CNC aluminum alloy and the top-tier T700 carbon fiber plates for durability

Customized Mounting: The kit includes a special silicone damping board plugin for DJI O3 Air Unit camera installation, eliminating jello in the DVR.

Streamlined Appearance: High-quality TPU components ensure a neat and integrated installation for an overall clean look.

Reliable Hardware: Provided hardware features Loctite thread-locking adhesive to ensure stability and prevent loosening.

Recommend Parts ( NOT Included):

Package Included:
2 x CNC Camera Mount (L&R)
1 x Keystone
4 x Arm
1 x Middle Plate
1 x Top Plate
1 x Bottom Plate
2 x Battery Strap
1 x Front Bumper
1 x Base Mount
1 x Antenna Mount
1 x Receiver Holder
1 x Arm Guard
4 x M25 Screw
4 x M28 Screw
4 x Φ4φ2h2
34 x M26 Screw
4 x M29 Screw
4 x M2 Anti-loosening Nut
4 x M1.612 Screw
4 x M223 Screw
1 x Battery Anti-slip Pad
2 x M225 Screw
4 x M220 Screw
2 x Silicone Vibration Damper (L&R)
